PCB Reverse Engineering China
PCB reverse engineering is the process of analyzing and recreating circuit board designs. It involves extracting schematics, layouts, and component data from existing PCBs. OurPCB offers expert PCB reverse engineering services in China, helping clients recreate or improve circuit designs efficiently.
PCB Reverse Engineering China
PCB Manufacturing Process
The Benefits of Partnering With OurPCB As Your China PCB Reverse Engineering Manufacturers?
- Highly skilled engineers with years of PCB analysis experience
- Continuous training in the latest reverse engineering techniques
- State-of-the-art scanning and imaging equipment
- Cutting-edge software for precise schematic recreation
- Competitive pricing without compromising quality
- Flexible service options to fit various budget needs
- Efficient processes to deliver results faster
- Regular updates on project progress
Why Choose PCB Reverse Engineering Services, China?
- Access to the latest PCB analysis tools and software
- Cutting-edge facilities for accurate reverse engineering
- Lower labor costs translate to affordable services
- Bulk orders lead to significant cost savings
- Efficient processes speed up project completion
- Quick prototyping and testing capabilities
- Extensive knowledge in handling diverse PCB types
- Expertise in working with global electronics standards
PCB Assembly Services
We use Surface Mount Technology for compact and high-performance PCB assembly. Our SMT process ensures precise component placement and soldering.
We offer flexible options for PCB assembly. We can work with your supplied components or provide full turnkey solutions, handling sourcing and assembly.
Our team delivers tailored assembly services to meet unique project needs. We adapt our processes to accommodate special designs or requirements.
We provide fast PCB assembly services without compromising quality. Our efficient processes ensure quick turnaround times for urgent projects.
We adhere to strict IPC Class 3 standards for high-reliability PCB assembly. This service is ideal for aerospace, medical, and other critical applications.
We handle assembly for all types of IC packages. Our expertise covers BGAs, QFNs, CSPs, and other complex package types.
Millions of business and innovators use OurPCB
Technical Capabilities
OurPCB boasts advanced technical capabilities for PCB reverse engineering. We use high-resolution X-ray systems and 3D scanning technology for detailed board analysis. Our software suite includes industry-standard tools for schematic capture and PCB layout recreation. We can handle boards up to 50 layers and work with various PCB materials. Our team is skilled in decoding complex circuits and identifying obsolete components.
Capabilities & Services
- One-stop PCBA Services (PCB Manufacturing + Components Sourcing + Assembly)
- SMT Assembly + THT Assembly, Single/double-sided Assembly Mixed PCB Assembly
- BGA Rework
- 60,000 Chips/Hour
- Down to 01005/0210 Size
- Accuracy<±40μm
- Min. QFN Pin Width/Space: 0.15mm/0.25mm
- Min. BGA Diameter/Space: 0.2mm/0.35mm
- Rigid PCB, Flex, HDI, & High-speed Power Boards
- Multilayer PCB Assembly (up to 64 layers)
- 60GHz High Frequencies
- Min. Trace Width/Spacing: 1.8mil/1.8mil
- AOI, X-ray, ICT & FCT Testing
- Controlled Impedance
- ISO 9001, ISO 13485, ISO 14001, IATF 16949, IPC-A-610, UL Certified
- Automotive, Medical, & Military-grade PCBA Manufacturing
Mon-Fri: 24 hours,
Sat: 9am-6pm, GMT+8
Reach us at
[email protected]
24 hours online
+86-199-30589219
Mon-Fri: 24 hours,
Sat: 9am-6pm, GMT+8
Reverse Engineering PCB China FAQs
Can you make a PCB clone that is 100% the same as the original board?
A PCB copy can replicate an original PCB design, using engineering files. However, slight variations can occur during PCB manufacturing, despite using precise Gerber file inputs. The PCB board may differ slightly from the original PCB due to production limitations. Multilayer and PCB module specifics can affect PCB production accuracy.
If reverse engineering is not precisely cloning the original design, what is it for?
The reverse engineering process uncovers the PCB schematic diagram, BOM list, and design. It helps understand the original PCB functionality for future PCB design improvements. It also enables IC unlock to modify or improve the electronic product. Reverse engineering allows accurate replication of similar or new board designs.
Is a PCB sample re-usable?
A physical PCB sample is typically not reusable due to potential wear during PCB service. However, the PCB file or Gerber file can be reused for PCB production. In some cases, a multilayer PCB may be reworked or modified for use. Engineering files are crucial for evaluating the reusability of a PCB board.
Order options
Quick-turn reverse engineering with schematic extraction and BOM generation.
Batch reverse engineering with design optimisation and documentation.
Scaled reverse engineering services with full design verification.
★ What customers say
Pricing on the reverse-engineered boards run was noticeably better than our previous supplier.
Their engineers flagged two DFM issues on our reverse-engineered boards before production — saved us a respin.
Third reorder of reverse-engineered boards from OurPCB — consistent every time.
The reverse-engineered boards arrived well-packed with full test reports included.
Build quality on the reverse-engineered boards was excellent; every unit passed our incoming inspection.
