PCB Assembly Services from China
OurPCB provides professional PCB assembly services with precision and reliability. Based in China, we deliver high-quality PCB assembly directly to customers in the USA and across the globe. Our end-to-end solutions include component sourcing, SMT, and through-hole assembly, ensuring efficient production and consistent quality from a single trusted PCB manufacturer.
We also specialize in circuit card assembly solutions, ensuring all your components are properly placed and connected for optimal performance. Whether you’re working with HDI PCBs or need specialized testing such as In-Circuit Testing for PCBs, our services provide you with a one-stop solution for all your needs.
For more advanced applications, we also offer selective gold plating processes to enhance your PCB’s performance in sensitive areas that require high conductivity and corrosion resistance. Additionally, effective PCB Thermal Management is crucial for maintaining component reliability and preventing overheating in high-performance electronic assemblies.
| Specification | PCBA Capability |
|---|---|
| Placer speed | 600,000 chips/hour |
| Lead Time | 25+ Days (To Be confirmed) |
| SMT | SMT, Through Hole Assembly Single/Double-Side SMT, Single/Double-Sides Mixture Assembly |
| PCB Size | 50mm×50mm ～610mm×508mm |
| PCB Thickness | 0.5mm～4.5mm |
| Min. diameter /space of BGA | 0.2mm/0.35mm |
| Qualifications | ISO 9001:2015 |
| Accuracy | <±30µm, under the condition of 3σ，CPK≥1 |
| Minimum width/space of QFP | 0.15mm/0.25mm |
| Minimum Diameter /Space of BGA | 0.2mm/0.35mm |
| Reliability Test | Flying Probe Test/Fixture test, Impedance Test, Solderability Test, Thermal Shock Test, Hole Resistance Test, and Micor Metallographic Section Analysis, etc. |
PCB Manufacturing Process
Our PCB Assembly Services
Our state-of-the-art equipment and technology allow us to provide a seamless assembly experience no matter what you need. Below are the expert PCB assembly services we offer:
✔️ SMT, THT, and mixed technology
✔️ Automated process for precision
✔️ Detailed inspection and quality control
✔️ Functional testing
✔️ Fast turnaround times
✔️ From 25 to 5,000 units
✔️ Quick turnaround (1 to 7 days)
✔️ Rigorous checking and testing
✔️ All component sizes
✔️ Leaded or lead-free solder
✔️ 24-hr to 7-day turnaround time
✔️ Fabrication and assembly
✔️ Low- to high-volume
✔️ RoHS-compliant circuit boards
✔️ Rapid prototyping
✔️ Design and assembly
✔️ Quality component sourcing
✔️ Electrical safety testing
✔️ Fortify existing cables
✔️ Off-the-shelf cables available
PCB Assembly Service Cost?
The PCB assembly cost for 50 units, each with 100 square inches, will range from $100.00 to $250.00, based on an assembly rate of $0.02 to $0.05 per square inch.
| PCB Specifications | Quantity | Cost per PCB (USD) | Total Cost (USD) |
|---|---|---|---|
| PCB Manufacturing (Size: 10x10cm, FR4 Material, 2 Layers) | 50 | $1 to $5 | $50.00 to $250.00 |
| PCB Assembly (Square Inch Assembly Cost) | 50 | $0.02/inch² (100 inch²/PCB) to $0.05/inch² (100 inch²/PCB) |
$100.00 to $250.00 |
This is a general estimate, and actual costs may vary based on several factors. For detailed pricing information, please visit our cost page.
PCB Assembly Lead Times Overview
| Service Type | Lead Time |
|---|---|
| Standard PCB Manufacturing | 5-6 days |
| Expedited Manufacturing | 24-48 hours |
| PCB Prototyping (Quick Turn) | 1-12 layers: within 72 hours |
| 12+ layers: within 120 hours | |
| PCB Assembly | 4-25 days, depending on complexity and order volume |
More PCB Assembly Fabrication Services
More PCB Assembly Fabrication Services
Why Choose OurPCB Assembly Services?
Our PCB assembly service is designed to exceed your expectations. Here’s why Our PCB is the ideal PCB assembly and manufacturing partner:
- Electronics Manufacturing Services (EMS) are offered to handle the entire lifecycle of your product.
- We ensure compliance with IPC Certification and Compliance, guaranteeing your product adheres to industry standards.
- Our capabilities include advanced PCBA Explained services, ensuring that your designs are fully functional and reliable before mass production.
- We provide RoHS and Lead-Free PCB Assembly Services, with rapid prototyping and full-scale production, no matter the size of your project.
We’ve provided over 3,000 happy customers with cost-effective high volume PCB assembly services. You could be next!
We’ve been a one-stop PCB assembly service for over 17+ years. Our capabilities are built on years of industry expertise.
Our exceptional PCBs and our electronic manufacturing processes meet all safety standards.
OurPCB is committed to validating, fabricating, assembling, and shipping your finished products with rapid turnaround times.
We’re proud to own two ISO 9001:2015 certified PCB assembly factories; one in Shenzhen and one in Shijiazhuang.
We work with only the best suppliers to provide you with durable, high-quality parts that perform.
We’re committed to providing you with the best service possible, even after you’ve received your product. Contact us at any time for help from our experts.
Whether you need a PCB prototype, component sourcing, or full-scale production, we can help. We’re your one-stop solution for all your PCB needs.
